Paper Machine Forming Wires

If you are interested in our paper machine forming wires, welcome to buy or wholesale the quality products with our factory. As one of the leading manufacturers and suppliers in China, we must be your best choice.



Paper Machine Forming Wires

A sheet of paper is created in the forming section where a mixture of roughly 99% water and 1% cellulose fiber and filler materials is introduced evenly across the width of a forming fabric. The fabric acts as a conveyor and a dewatering device. As the fabric moves, water drains through it, while the fibers and fillers that form the paper structure form on the top of the fabric as the paper sheet is created. It is critical that the fabric provides a stable, durable environment to aid this process. Forming fabrics can last from 1 to 6 months.  Multilayer technology created by KAIBANG industry is the standard today paper machines worldwide.

Technical Specification:

Weaving Series and Types	Model of Fabric	Thread Diameter       mm		Density (pieces /cm)		Strength (N/cm)		Thick- ness mm	Air Perm-eation m3/m2h	Max. Elongation at 50N/cm
		Warp	Weft	Warp	Weft	Mesh Surface	Inserting Place
2.5 Layer Forming Screen	6025	0.17	0.13,0.17       0.20,0.20	68	62	=960	=600	0.70	5500	0.46%
	6035	0.17	0.13,0.20       0.35,0.35	68	49	=960	=700	1.00	6500	0.45%
	3850	0.27	0.20,0.25       0.50/0.50	43	34	=1500	=1000	1.44	7500	0.45%
	4345	0.20	0.20,0.25       0.45,0.45	49	41.5	=1100	=850	1.25	6200	0.45%
